GENERAL
FEATURES
Specification
| Model | Voltage(V) | Rated Capacity(AH) | LENGTH | WIDTH | HIGHT | T.HIGHT | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | in | mm | in | mm | in | mm | in | ||||
| 12V1.2Ah | 12V | 1.2Ah | 97 | 3.82 | 43 | 1.69 | 52 | 2.05 | 58 | 2.28 | 12V1.2Ah |
| 12V1.9Ah | 12V | 1.9Ah | 178 | 7.01 | 35 | 1.38 | 61 | 2.40 | 67 | 2.64 | 12V1.9Ah |
| 12V3.0Ah | 12V | 3.0Ah | 135 | 5.32 | 67 | 2.64 | 61 | 2.40 | 67 | 2.64 | 12V3.0Ah |
| 12V4.0Ah | 12V | 4.0Ah | 90 | 4.37 | 70 | 2.76 | 103 | 4.06 | 108 | 4.25 | 12V4.0Ah |
| 12V4.5Ah | 12V | 4.5Ah | 90 | 4.37 | 70 | 2.76 | 103 | 4.06 | 108 | 4.25 | 12V4.5Ah |
| 12V5.0Ah | 12V | 5.0Ah | 151 | 5.94 | 53 | 2.09 | 93 | 3.67 | 99 | 3.90 | 12V5.0Ah |
| 12V7.0Ah | 12V | 7.0Ah | 151 | 5.94 | 65 | 2.56 | 94 | 3.70 | 100 | 3.93 | 12V7.0Ah |
| 12V7.5Ah | 12V | 7.5Ah | 151 | 5.94 | 65 | 2.56 | 94 | 3.70 | 100 | 3.93 | 12V7.5Ah |
| 12V12Ah | 12V | 12Ah | 152 | 5.98 | 98 | 3.86 | 95 | 3.74 | 101 | 3.97 | 12V12Ah |
| 12V17Ah | 12V | 17Ah | 181 | 7.12 | 77 | 3.03 | 167 | 6.571 | 167 | 6.57 | 12V17Ah |
| 12V26Ah | 12V | 26Ah | 174 | 6.84 | 166 | 6.5 | 126 | 4.94 | 126 | 4.94 | 12V26Ah |
| 12V7.5Ah | 12V | 7.5Ah | 151 | 5.94 | 65 | 2.56 | 94 | 3.70 | 100 | 3.93 | 12V7.5Ah |
| 12V33Ah | 12V | 33Ah | 195 | 7.68 | 130 | 5.12 | 155 | 6.11 | 179 | 7.25 | 12V33Ah |
| 12V40Ah | 12V | 40Ah | 197 | 7.76 | 166 | 6.5 | 170 | 6.7 | 170 | 6.7 | 12V40Ah |
| 12V65Ah | 12V | 65Ah | 350 | 13.98 | 167 | 6.57 | 180 | 7.08 | 180 | 7.08 | 12V65Ah |
